Model: XBS40

Item specifics

Concrete pumping capactiy: 40m3/h

concrete pumping height: 120m

concrete pumping distance: 300m

System Working Pressure: 25MPa

Concrete Cylinder: 140

Max. aggregate dimension: 30mm

power system: 48kw

Hydraulic oil circuit type: Open circuit

Lubrication: auto lubrication

Review

Description

China Factory Direct Supply JIUHE Brand XBS40 Mortar concrete pump For Sale

XBS series products are a kind of mortar conveying equipment specially developed according to the characteristics of floor heating projects. They are extensively applied in the large area and highly efficient construction of fine stone concrete or mortar stuffing in floor heating projects.XBS series products are also widely used for the conveying of fine stone concrete, fir-resistant and heat-insulating materials in various construction projects; the delivery of afforesting soil in eco-environmental construction; the pressure grouting of various basic piles.

Features

Extend component life

overall hydraulic commutation system: the alternative commutation actions between pumping and S tube distribution doesn't involve electric signals. Little impact and noise occurs during the commutation, so the service lives of the hydraulic pump and valves are evidently lengthened.

Improve equipment reliability

Overall hydraulic system saves the intermediate process of the electric signals. In this way, the reliability of the whole equipment is greatly increased.

Reduce the failure rate

Full hydraulic commutation system adopts centralized valve plate, the hydraulic valves of main system are centralized in one valve plate. The number of cross-connected pipelines is reduced, the system gets more compact, at the same time the oil leaking possibility is decreased.

Video

JIUHE Fine Stone Mortar Concrete Pump for Sale

JIUHE is professional manufacturer in China for trailer concrete pump vary from 40m3/h to 100m3/h , we are factory directly supply, both quality and service can be ensured.

JIUHE Main Products:

Trailer concrete pump,

concrete line pump,

concrete pump truck,

concrete placing boom,

wet shotcrete machine,

ladder lift truck,

Aerial lift truck and so on.

Parameter

	Items	Units	Parameters
Whole machines performance	Theoretical max. discharging volume	m³/h	40
	Theoretical max. delivery pressure	Mpa	13
	Max. delivery frequency	times/min	30
	The type of distribution valve		S valve
	Specification of delivery cylinder	mm	Φ140×800
	Specification of main oil cylinder	mm	Φ80/Φ50×800
	Outlet opening diameter	mm	Φ125
	Hopper capacity	L	300
Power system	Rated voltage	V	～380
	Main motor power	Kw	45
	Rated speed	r/min	1470
	Assistant motor power	Kw	3
	Rated speed	r/min	1430
Hydraulic system	Hydraulic oil circuit type		Open circuit
	Max. oil pressure of pumping system	MPa	25
	Max. oil pressure of mixing system	MPa	9
	Max. mixing speed	r/min	24
	Oil tank capacity	L	200
Other parameters	Max. diameter of aggregates	mm	30
	Inner dia. of delivery pipe	mm	Φ80
	Dimension (length×width×height)	mm	4300×1500×1500
	Overall weight	Kg	2100
	Pulling speed	Km/h	≤8
